Specification
| Camera Feature | ||
| Image Sensor | 1/2.7″ CMOS | |
| Effective Pixels | 1920(H)×1080(V), 2MP | |
| IR Distance | Up to 20m (66feet) | |
| Others | IR On/Off Control: Auto / Manual Scanning System: Progressive Minimum Illumination: 0.04Lux/F1.85, 30IRE, 0Lux IR on S/N Ratio: More than 65dB |
|
| Lens | ||
| Type | Fixed lens / Fixed iris | |
| Focal Length | 3.6mm (2.8mm, 6mm Optional) | |
| Aperture | F1.85 (max.) | |
| Angle of View | H: 93° (103°, 54.7°) | |
| Others | Focus Control: N/A Close Focus Distance: 800mm (500mm, 2000mm) 31.5” (19.69”, 78.74”) Mount Type: Board-in |
|
| Physical Specification | ||
| Dimension | 69.8mm×69.8mm×157.6mm (2.75″×2.75″×6.20″) | |
| Weight | Net Weight: 0.25kg (0.55lb) Gross Weight: 0.30kg (0.66lb) |
|
| Power | Power Supply: 12V DC ±30% Power Consumption: Max. 2.7W (12V DC, IR on) |
|
| Brand | Dahua |
|---|
