Specification
| General | ||
| Casing | Aluminium | |
| Dimensions | Φ106mm×93.7mm (Φ4.17″×3.69″) | |
| Weight | 0.44 Kg | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360° |
|
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH | |
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH | |
| Power Supply | 12V DC ±30% | |
| Power Consumption | Max 4.2W (12V DC, IR on) | |
| Camera | ||
| Image Sensor | 1/2.7″ CMOS | |
| Effective Pixels | 1920(H)×1080(V), 2MP | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
|
| Minimum Illumination | 0.02Lux/F1.85, 30IRE, 0Lux IR on | |
| S/N Ratio | More than 65dB | |
| IR Distance | Up to 50m (164feet) | |
| IR On/Off Control | Auto / Manual | |
| IR LEDs | 1 | |
| Lens | ||
| Lens Type | Fixed lens / Fixed iris | |
| Mount Type | Board-in | |
| Focal Length | 3.6mm | |
| Max Aperture | F1.85 | |
| Angle of View | H: 87.5° (103°, 54.7°) | |
| Close Focus Distance | 500mm (900mm, 2000mm) 19.69” (35.43″, 78.74”) |
|
| Video | ||
| Resolution | 1080P (1920×1080) | |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) |
|
| Day/Night | Auto (ICR) / Manual | |
| BLC Mode | BLC / HLC / DWDR | |
| Gain Control | AGC | |
| Noise Reduction | 2D | |
| Interface | ||
| Audio Interface | Built-in Mic | |
| Special Features | ||
| Features | Ingress Protection & Vandal Resistance: IP67 White Balance: Auto / Manual Smart IR: Auto / Manual |
|
| Warranty | ||
| Warranty | 1 Year | |
| Brand | Dahua |
|---|
